SKFBSD 50100 CG參數
| 角接觸推力球軸承 for screw drives, single direction | |||||||||||
| 主要數據尺寸 | 基本負荷額定值 | 疲勞負荷限值 | 可達到的速度 | 體積 | 型號 | ||||||
| 動態 | 靜態 | 當潤滑與 | SKF | SNFA | |||||||
| 油脂 | 滴油潤滑 | ||||||||||
| d | D | H | C | C0 | Pu | ||||||
| mm | kN | kN | r/min | kg | - | ||||||
 | |||||||||||
| 50 | 100 | 20 | 67 | 193 | 7,2 | 5600 | 6700 | 0,71 | BSD 50100 CG | BS 50/100 7P62U | |
SKFAngular contact thrust ball bearings for screw drivesBSD 50100 CG屬于超高精密軸承，它是角接觸推力球軸承 for screw drives, single direction的Angular contact thrust ball bearings for screw drives，內徑：50，外徑：100，厚度20，SKFBSD 50100 CG主要應用于工程機械、等領域。如果您需要購買或者了解更多關于SKFBSD 50100 CG的信息， 歡迎撥打訂購熱線：022-27921004
- SKFBSD 50100 CG近似型號
- SKF BSD 50100 CG 尺寸：50mm × 100 × 20 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, single direction
- SKFBSD 50100 CG相關型號
- SKFBEAS 025057-2RS 尺寸：25mm × 57 × 28 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, single direction
- SKFBSD 60120 CG 尺寸：60mm × 120 × 20 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, single direction
- SKFBSA 215 CG 尺寸：75mm × 130 × 25 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, single direction
- SKFBEAS 008032-2RS 尺寸：8mm × 32 × 20 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, single direction
- SKFBSA 307 CG 尺寸：35mm × 80 × 21 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, single direction
- SKFBEAS 017047-2Z 尺寸：17mm × 47 × 25 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, single direction
- SKFBSD 2047 CG 尺寸：20mm × 47 × 15 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, single direction
- SKFBSA 308 CG 尺寸：40mm × 90 × 23 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, single direction
- SKFBSD 4575 CG 尺寸：45mm × 75 × 15 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, single direction
- SKFBSD 55120 CG 尺寸：55mm × 120 × 20 類型：Angular contact thrust ball bearings for screw drives 備注：角接觸推力球軸承 for screw drives, single direction
- SKFBSD 50100 CG推薦型號
- GMN 71918C/DB 尺寸：90mm × 125 × 36 類型：
- NTN 7209B/DF 尺寸：45mm × 85 × 38 類型：
- KOYO 29472 尺寸：360mm × 640 × 170 類型：
- KOYO 32228 尺寸：140mm × 250 × 68 類型：
- KOYO 32312 尺寸：60mm × 130 × 46 類型：
- STEYR N240 尺寸：200mm × 360 × 58 類型：
- KOYO NJ212+HJ212 尺寸：60mm × 110 × 22 類型：
- KOYO NJ309+HJ309 尺寸：45mm × 100 × 25 類型：
- RHP NF318 尺寸：90mm × 190 × 43 類型：
- SKF LM245846/810 尺寸：230.188mm × 317.5 × 47.625 類型：
